Maintenance E 3000
8.9 Cleaning the Turbulators and the Exhaust Ducting
Requirements  Machine shut down
 Machine cool
Procedure Follow the procedure below to clean/change the turbulator tubes.
1. Allow the machine to cool.
2. Remove the nuts (a) that secure the flue box door (b).
3. Open the flue box door.
NOTICE: If the door panel insulation does not open with the door, carefully remove
it from where it is caught on the bolts (c). Inspect all panels for damaged insulation.
Replace all damaged panels.
4. Locate the turbulators housed in the burner tubes.
5. Remove the turbulators (d) by pulling the turbulator tab. Replace any turbulator
that is badly eroded.
6. Clean each burner tube with a bottle brush.
This procedure continues on the next page.
WARNING
Burn hazard. The hydronic heater is very hot when the machine is operating. When
hot it can cause severe burns.
f Allow the machine to cool before performing this procedure.

Wacker Neuson E3000 Specifications

General

Electrical Requirements	230 V, 50 Hz
Voltage	230 V
Operating Voltage	230 V
Heat Capacity	3000 W
Fuel Consumption	0.3 l/h
Tank Capacity	12 l
Fuel Tank Capacity	12 l
Heating Capacity	3000 W
Fuel Consumption (l/h)	0.3 l/h
Tank Capacity (l)	12 l
Power Consumption	3 kW
