Wacker Neuson E3000 User Manual

wc_tx001803gb.fm
150
Maintenance E 3000
8.12 Installing the Burner
Requirements  Power supplies disconnected
 Machine cool
Procedure Follow the procedure below to install the burner.
1. Position the burner inside the machine and secure it to the hydronic heater.
2. Reconnect the wiring from the snap switch cable (c) and burner cable (d) to the
burner controller.
3. Mount the burner controller (b) to the burner.
4. Connect the fuel lines (a) at the quick-connects.
Result The procedure to install the burner is now complete.
wc_gr008595
c
d
b

Wacker Neuson E3000 Specifications

General

Electrical Requirements	230 V, 50 Hz
Voltage	230 V
Operating Voltage	230 V
Heat Capacity	3000 W
Fuel Consumption	0.3 l/h
Tank Capacity	12 l
Fuel Tank Capacity	12 l
Heating Capacity	3000 W
Fuel Consumption (l/h)	0.3 l/h
Tank Capacity (l)	12 l
Power Consumption	3 kW
