Burner Setup—Gas E 3000
7.3 Setting up the Burner
Background
The burner consists of several different components and subsystems. Each of
these components or subsystems must be operating correctly for the burner to
function properly.
Tools required
The following tools are required to adjust the burner:
High-quality combustion analyzer
Smoke spot tester
Manometer
General hand tools
Mandates
Adjustments made shall be done so that the machine conforms to the
requirements of local, state, and federal codes and authorities.
Adjustments shall be made at the job site.
When to
adjust
Adjust the burner:
Before operating the machine at elevations 305 m (1,000 ft) above or below the
location of where the last adjustments were made
Before starting at a new job site
After any burner maintenance or repair has been performed
If burner performance is in question
Procedure
Follow the procedure below to set up the burner.
1. Shut down the machine.
2. Adjust the ionization probe and the electrode.
(See topic 7.4)
3. Check the burner orifice.
(See topic 7.5)
4. Set the air settings.
(See topic 7.6)
5. Adjust the head setting.
(See topic 7.7)
6. Check/set the supply gas pressure.
(See topic 7.8)
7. Start the machine and the burner.
8. Check/set the burner gas pressure.
(See topic 7.9)
This procedure continues on the next page.
