E 3000 Operation
4.16 Connecting Power to the Machine
Prerequisites
Power source
Machine properly positioned
Extension
cords
Restrictions for extension cords:
Use only 3-wire type extension cords with heavy-duty plugs.
The maximum length of extension cord usage per circuit is 30 m (100 ft).
Use 12-gauge extension cords for lengths up to 15 m (50 ft).
Use 10-gauge extension cords for lengths up to 30 m (100 ft).
Procedure
Follow the procedure below to connect power to the machine.
1. Move both circuit breaker switches (a and b) to the OFF position.
2. Connect the main power cords (c) to a properly-rated power source or to the
generator (d) if included.
Result
Power has now been connected.
WARNING
Fire hazard and electric shock hazard. The use of undersized extension cords can
lead to fire and electric shock. Fire and electric shock can cause severe injury.
f Do not use undersized extension cords.
wc_gr008601
POWER 1
POWER 2
c
d
a
b
