E 3000 Accessories
5.5 Mounting and Connecting the Auxiliary Pump Panel
Prerequisites  Machine shut down
 Power disconnected
Background The Wacker Neuson Auxiliary Pump Panel (APP) is an electrical device that
communicates with the main machine’s systems to provide protection for any
additional Pump Packs that are connected to the machine. If the machine
experiences a low level fault condition, the APP will cut off power to the external
components. This power cut-off protects the pumps from damage.
Guidelines Follow the guidelines below when mounting the APP. Refer to the diagram below.
 Install inside the machine, near the main control panel (a).
 Install using included hardware (b).
This procedure continues on the next page.

Wacker Neuson E3000 Specifications

General

Electrical Requirements	230 V, 50 Hz
Voltage	230 V
Operating Voltage	230 V
Heat Capacity	3000 W
Fuel Consumption	0.3 l/h
Tank Capacity	12 l
Fuel Tank Capacity	12 l
Heating Capacity	3000 W
Fuel Consumption (l/h)	0.3 l/h
Tank Capacity (l)	12 l
Power Consumption	3 kW
