Accessories E 3000
Continued from the previous page.
Ref Description Condition
#1 Pump pack supply valve 1 Open after connection
#4 Right HTF supply valve Open after connection
#5 Cross connect valve Closed
#6 Left HTF supply valve Open after connection
#7 Pump pack supply valve 2 Open after connection
a First DPP Connected to E 3000 and HHS 3002
b Hose loop from left reel Placed in application area
c Hose loop from right reel Placed in application area
d First HHS 3002 hose loop 1 Placed in application area
e First HHS 3002 hose loop 2 Disconnected from first HHS 3002 hose loop
1 and placed in application area
f First HHS 3002 frame Placed in safe location
g Return port Used for HSS 3002 loop 1
h Return port Used for HHS 3002 loop 2
i / j 2-1 adapter Connected to return port
k Second HHS 3002 hose loop 1 Placed in application area
l Second HHS 3002 hose loop 2 Disconnected from second HHS 3002 hose
loop 1 and placed in application area
m Second DPP Connected to E 3000 and HHS 3002
n Second HHS 3002 frame Placed in safe location
x First DPP leader hose Connected to E 3000 and HHS 3002
y Second DPP leader hose Connected to E 3000 and HHS 3002
