Accessories E 3000
Continued from the previous page.
Electrical
connections
After mounting, carry out the steps below to complete the electrical connections.
1. Connect the DIN leader (a) from the main control panel to the corresponding
DIN leader on the APP (b).
2. Connect a properly-rated extension cord (c) to the power cord (d) on the APP.
3. Connect the Pump Pack power cord (f) to the APP power adapter (e).
Result
The APP is now mounted and connected. Continue with normal operation.
