waratah HTH623C - Waratah Switch Control (Two-Position)

Safety:MaintenancePrecautions
T7M7G6M,0000851-19-25MAY22-1/1
WaratahSwitchControl(Two-position)
TheWaratahswitchcontrolhastwopositions:Offand
On.Theseworkinconjunctionwiththecarriercontrols
asdescribedbelow.
Off
WhentheswitchcontrolisintheOffposition:
•
Hydraulicpower,controllercommunications,and
electricalpowertoharvesterheadsolenoidsare
disabled.
•
Therotatorsystemiscontrolledbycarrierhydraulics.
On
WhentheswitchcontrolisintheOnposition:
•
Electricalpowerandcommunicationstotheharvester
headsystemareenabled.
•
TheWaratahcontrollerison.
WhencarrierhydrauliccontrolsareOn/enabled:
•
Waratahharvesterheadfunctionsareenabled.
•
Hydraulicpowertothecarriermachineisenabled.
•
Carrierhydrauliccontrolsareenabled.
XJ1321583—UN—09MAR22
Waratahswitchcontrol
WhencarrierhydrauliccontrolsareOff/disabled:
•
Harvesterheadhydraulicfunctionsarenotactive.
•
Hydraulicpowertothecarriermachineisdisabled.
•
Carrierhydrauliccontrolsaredisabled.
NOTE:Manualmodefortroubleshootingisactivated
fromtheTimberRite™H-16softwarerather
thanviatheswitch.
TimberRiteisatrademarkofDeere&Company
1-3-5
