waratah HTH623C - Fault-Finding

Maintenance—General
t7m7g6m,1652959504986-19-19MAY22-1/1
DS17474,000005C-19-05JUL19-1/1
RecommendedHarvesterHeadPositions
forMainSawChainandMainSawBar
Maintenance
CAUTION:Theharvesterheadcanmove
unpredictably.Alwayslowertheharvesterhead
tothegroundwhencarryingoutmaintenance.
Seriousinjuryordeathcanoccur.
CAUTION:Preventharvesterheadfrombeing
accidentallyactivated.Alwaysstopcarrierengine
andisolatetheWaratahcontrollerlocatedin
carriercab.Seriousinjuryordeathcanoccur.
1.Lowerharvesterheadtotheground.
2.Openfeedarms(2).
3.Activateupperdelimbknives(3)totheclosedposition.
4.Activatebaillock.
5.TurnofcarrierandWaratahcontroller.
CAUTION:Preventtheharvesterheadfrom
moving.Alwaysensurethatthetiltframeisinthe
harvestingorprocessingpositionandthelocking
pinisinstalled.Seriousinjuryordeathcanoccur.
6.Insertthelockingpinintheprocessingposition(5).
CAUTION:Preventinjuryfromyingorsharp
objects.Alwayswearapprovedglovesandeye
6
5
3
2
2
TX1059827—UN—26MAY09
2—FeedArm
3—UpperDelimbKnife
5—LockingPininProcessing
Position
6—MainSaw
protectionwhenperformingsawchainorsawbar
maintenance.Seriousinjuryordeathcanoccur.
7.Pullthemainsaw(6)downoutofthemainsawbox.
Fault-Finding
General
Withanyfaultnding,therststepistodecidewhere
toinvestigate.Sometimesthisisobvious,butonother
occasionsfurtherinvestigationisrequired.Alogical,
ratherthanhaphazard,approachtomakingadjustments
orreplacingparts,ismoreeffective.
Alwaystakeintoaccountanywarningsignsor
abnormalitiesthatmayhavebeennoticedintheperiod
precedingthefault(forexample,powerloss),and
remember:failureofacomponentsuchasacircuit
breaker,mayonlybeasymptomofanunderlyingfault.
Whateverthefault,certainbasicprinciplesapply.These
areasfollows:
1.Verifythefault.
Ensuresymptomsareidentiedbeforestartingwork.
Thisisparticularlyimportantwheninvestigatingafault
someoneelsehasdescribed.
2.Donotoverlooktheobvious.
Forexample,ifanelectricalfaultisindicated,check
thediagnosticindicatorsbeforealteringthewiring.
3.Curethedisease,notthesymptom.
4.Donottakeanythingforgranted.
Beawarethatnewcomponentsmaybedefective;do
notleavecomponentsoutofadiagnosissequence
justbecausetheyareneworrecentlytted.Whena
faultisdiagnosed,thekeyevidenceisoftenonhand
fromthestart.
3-3-2
053122
PN=72
