Miscellaneous—Carrier
AM24480,00001A6-19-26SEP14-1/6
ContinuedonnextpageAM24480,00001A6-19-26SEP14-2/6
WeldingonCarrierorHarvester
Head—TimberRite™
1.Parktheharvesteronaat,evensurface.
IMPORTANT:Electricalsystemdamagecanoccurby
anelectricalweldercurrent;electricalequipment
mustbeisolated.Failuretoisolateelectrical
equipmentcandamagetheelectricalsystem
andmayrequirecomponentreplacement.
2.TurntheTimberRite™key-switchtothe“off”position.
3.Turnoffanyelectronicswireddirectlyfromthebattery.
4.Turnoffthemainpowertothecarrier.
5.Disconnectthecarrierbattery.
TX1022193—UN—17MAY07TX1033494A—UN—14DEC07
TimberRiteisatrademarkofDeere&Company
6.Disconnectthepowerconnector(1)tothecontroller.
7.DisconnecttheCAN1connector(3).
1—Powerconnector
3—CAN1connector
1
3
XJ1162926—UN—11JUN14
TimberRite™ControllerModule
4-1-3
053122
