waratah HTH623C - Grease Point Location-Tilt Frame Pin Grease Point

Maintenance—FluidsandLubricants
T7M7G6M,0000458-19-19MAY22-1/1
GreasePointLocation—TiltFramePin
GreasePoint
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failuretofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
TiltFramePin1
1—TiltFramePinGrease
Fitting
2—TiltFramePinGrease
FittingHose
1
2
TX1062581—UN—07AUG09TX1062584A—UN—07AUG09
3-1-7
053122
