AvoidChainShot
XJ1135231—UN—18APR13
SawchainBreakwithoutSawchainshotGuard
XJ1134867—UN—12APR13
SawchainBreakwithSawchainshotGuard
15
15
15
15
XJ1134865—UN—18APR13
SawchainshotHazardZone
XJ1134861—UN—12APR13
SafetySign
Chainshotisthehighvelocityseparationandejection
ofapieceorpiecesfromtheendofabrokensawchain
duringmechanizedtimberharvesting.
CAUTION:Sawchainshotexposesmachine
operatorsandbystanderstodeathor
seriousinjury
Chainshottypicallyoccursnearthesawdrivesprocket
ofthecuttingsystem;itcanalsocomefromthesawbar
tip.Chainshotpiecestypicallytravelwithin15degrees
oneithersideofthesawbarplane.
Achainshotconsistsoftwobreaksinasawchain.First,
thesawchainloopbreaksandformstwoends.Oneend
movespastthesawchaindrivesprocketorsawbartipand
israpidlyacceleratedduetomotionofthesawchainend.
Thewhipactioncausesasecondbreakinthesawchain,
ejectingpiecesofthecuttingsawchainathighspeed.
