waratah HTH623C - Grease Point Location-Upper Delimb Knives

Maintenance—FluidsandLubricants
T7M7G6M,0000459-19-19MAY22-1/1
GreasePointLocation—UpperDelimb
Knives
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failingtofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
UpperDelimbKnife
Right1
UpperDelimbKnifeLeft
1
UpperDelimbLink2
UpperDelimbKnifeCylinder
2
1—LeftUpperDelimbKnife
Link
2—LeftUpperDelimbKnife
CylinderBarrelEnd
3—LeftUpperDelimbKnife
4—RightUpperDelimbKnife
5—RightUpperDelimbKnife
CylinderRodEnd
6—RightUpperDelimbKnife
Link
2
1
3
TX1062595—UN—07AUG09
LeftUpperDelimbKnife
5
4
6
TX1062596—UN—07AUG09
RightUpperDelimbKnife
