waratah HTH623C - Grease Point Location-Lower Delimb Knife

Maintenance—FluidsandLubricants
T7M7G6M,000045C-19-19MAY22-1/1
GreasePointLocation—LowerDelimbKnife
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failingtofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
LowerDelimbKnifeRodEndLeft
1
LowerDelimbPin1
LowerDelimbKnifeBarrelEnd
GreaseHose
1
1—LowerDelimbKnife
CylinderRodEnd
2—LowerDelimbKnifePin
3—LowerDelimbKnife
CylinderBarrelEnd
1
2
TX1062632—UN—07AUG09
3
TX1062906—UN—12AUG09
3-1-11
053122
PN=60
