waratah HTH623C - Maintenance-Every 8 Hours or Daily

Maintenance—Schedule
T7M7G6M,000045F-19-03JUN20-1/1
Maintenance—Every8HoursorDaily
CAUTION:Preventpossibleinjuryworking
inthearmcapturezonesorthesawbar
openingoftheharvesterhead;stoptheengine.
Failingtofollowthesesafetyprecautions
mayleadtoseriousinjury.
IMPORTANT:Sawcomponentswearmorerapidlyin
coldtemperatures.Ensurethesawchainis
keptlubricatedatalltimes.Failingtodoso
mayresultinlinkfailure,andthesawchain
maybeejectedathighspeed.
1.Lubricateallgreasettings.Lubricatetwicepershift
ifworkinginhardwoodapplications.(RefertoFluids
andLubricants.)
2.Fillsawchainlubricationreservoir,onlefthandside
oftheharvesterhead.Cleantheareaaroundthe
reservoircapofalldebrisanddirtandremovethecap.
Fillcompletelywithsawchainoilpertherecommended
sawchainoilchart.(RefertoFluidsandLubricants.)
3.Conductoverallvisualinspection.Checkvalve,
motors,cylinders,andallhosesforleaksorwear.
Tightenorreplacettingsandhosesasnecessary.
4.Checktopsawandmainsawchaincondition.Inspect
sawchainsforexcessivewear,cracking,orbroken
teeth.Replacesawchainifnecessary.
5.Checkchainshotguard.SeeChainShotGuard
Inspection.
TX1019790—UN—20MAR07TX1019793—UN—20MAR07
6.Conductvisualinspectionofthemeasuringequipment
andsensors.Ensuretheyareclean,clear,andfree
ofobstacles.
