waratah HTH623C - Grease Point Location-Feed Arms

Maintenance—FluidsandLubricants
T7M7G6M,000045B-19-19MAY22-1/1
GreasePointLocation—FeedArms
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failingtofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
FeedRollerArmRight1
FeedRollerArm
Left
1
FeedRollerArmLink2
FeedRollerArmCylinder
Right2
FeedRollerArmCylinderLeft
2
FeedRollerHub2
1—LeftFeedRollerArm
CylinderBarrelEnd
2—LeftFeedRollerArm
CylinderRodEnd
3—LeftFeedRollerArm
4—LeftFeedRollerArmLink
5—RightFeedRollerArm
CylinderBarrelEnd
6—RightFeedRollerArm
CylinderRodEnd
7—RightFeedRollerArm
8—RightFeedRollerArmLink
3
2
4
1
TX1062617—UN—07AUG09
LeftFeedRollerArm
6
7
8
5
TX1062618—UN—07AUG09
RightFeedRollerArm
