waratah HTH623C - Grease Point Location-Tilt Frame

Maintenance—FluidsandLubricants
T7M7G6M,0000457-19-19MAY22-1/1
GreasePointLocation—TiltFrame
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failuretofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
TiltFrame2
TiltCylinder
2
RotatorHousing1
RotatorRing2
Swivel
3
Link2
8
9
10
12
11
4
6
1
2
5
8
7
9
10
12
11
3
4
TX1059863—UN—28MAY09
1—Link
2—Link
3—RotatorRing
4—RotatorHousing
5—RotatorRing
6—Swivel
7—Swivel
8—Swivel
9—TiltFrame
10—TiltFrame
11—TiltCylinderBarrelEnd
12—TiltCylinderRodEnd
3-1-5
053122
PN=54
