Operation:SpecialTechniques
T7M7G6M,0000450-19-02JUN20-1/1
T7M7G6M,000064E-19-19FEB21-1/2
T7M7G6M,000064E-19-19FEB21-2/2
FellingonHillsides
Fellingtreesonhillsidesmaymeanthecuttingunitis
exposedtodirtandduffontheuphillsideoftrees.
Whenfellingonhillyterrain,ensuretheharvesterheadis
positionedcorrectly(5),ensuringthesawbartipdoesnot
foulthegroundonthehighsideofthetree.
5—Harvesterheadpositioned
correctly
5
TX1019724—UN—29MAR07
UsingLoadingProcessor
1.TheLoadingmodesymboldisplaysintheworkmode
window.IficonismissingcontactyourWaratah
servicetechnician.
XJ1302113—UN—19AUG20
2.ToenterLoadingmodeclicktheicon.Loadingmode
isindicatedinthemiddlearea.
3.WhenLoadingmodeisactivated,allbuttonsare
ignoredwiththefollowingexceptions:
RotateCWandrotateCCW
Tiltupandtiltdown
Headopenandheadclose
UDKdelimbopenandUDKdelimbclose
Feedarmopenandfeedarmclose
LDKdelimbopenandLDKdelimbclose
Slowfeedforwardandslowfeedreverse
NOTE:Themainandtopsawwillbelocked,andonly
slowfeedwillbeactiveonthefeedbuttons.Iffast
feedbuttonsarepressed,slowfeedwillactivate.
XJ1302114—UN—26AUG20
