waratah HTH623C - Grease Point Location-Tilt Frame for Loader Processor (Option)

Maintenance—FluidsandLubricants
T7M7G6M,0000409-19-19MAY22-1/1
GreasePointLocation—TiltFramefor
LoaderProcessor(Option)
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failuretofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
TiltCylinder
2
1
2
XJ1297722—UN—29MAY20
1—Tiltcylinderbarrel-end
greasepoint
2—Tiltcylinderrod-endgrease
point
3-1-6
053122
