waratah HTH623C - Features

General
ContinuedonnextpageT7M7G6M,0000453-19-02JUN20-1/2
Features
TX1062323
1
2
14
5
4
12
3
6
6
8
7
8
9
10
13
TX1062323—UN—31JUL09
HTH623CFeatureswithTopSawshown
Toassisttheoperatorinbecomingfamiliarwiththemany
featuresoftheHTH623CHarvesterHead,andthereby
quicklybecomeprocientintheoperationandperiodic
maintenanceprocedures,thismanualisprovidedwith
detailoperatingandmaintenanceinstructionsaswellas
safetyinformationandequipmentdata.
1.Link.Pivotpointbetweenthecarrierandtheharvester
head.
2.Rotator.Hydraulicdrivenrotationoftheharvester
head.
3.UpperDelimbCylinder.Controlstheupperdelimb
knives.
4.UpperDelimbLink.Movestheupperdelimbknives
inunison.
5.TopKnife.Debarksanddelimbsthetreeasitis
pulledthroughtheharvesterhead.
6.UpperDelimbKnives.Worksinconjunctionwiththe
topknifetodebarkanddelimbthetree.
7.FixedFeedRoller.Centermountedfeedrollerfeeds
thetreethroughtheharvesterhead.
8.FeedRollers.Usedtogripthetreeandworkinunison
withthexedfeedroller.
9.MainSaw.Performsthemainlengthcuttingoperation.
10.BottomKnife.Debarksanddelimbsthetreeasitis
pulledthroughtheharvesterhead.
11.FeedArm.Housesthefeedrollermotorsandletsthe
feedarmspivot.
12.MeasuringWheel.Rollsalongthelengthofthetree
andsendsmeasurementsignalstothemeasuring
system.
13.TiltFrame.Ushapedbracketthatpivotstheharvester
headverticalandhorizontal.
14.TopSaw(optional).Performsthetreetopping
operation.
0-1-3
