Operation:ThinningTechniques

T7M7G6M,0000446-19-02JUN20-1/1

SelectThinning

Thismethodisdependentuponnishedcropstocking

levels,asthisdeterminestheareaavailabletomaneuver

acarrierbetweentrees.

Thismethodallowsareductioninpathscutfromablock,

whilestillallowingaccessforextractioncarriers.

TX1050358—UN—29OCT08

2-3-2

053122

PN=43
