Maintenance—General
t7m7g6m,1652959478834-19-19MAY22-1/1
RecommendedHarvesterHeadPositionsfor
TopSawChainandTopSawBarMaintenance
CAUTION:Seriousinjuryordeathcanoccur.
Theharvesterheadcanmoveunpredictably.
Alwayslowertheharvesterheadtotheground
whencarryingoutmaintenance.
CAUTION:Seriousinjuryordeathcanoccur.
Preventharvesterheadfrombeingaccidentally
activated.Alwaysstopcarrierengineandisolate
theWaratahcontrollerlocatedincarriercab.
1.Tiltharvesterheadup.
2.Closefeedarms(2)anddelimbknives(3and5).
CAUTION:Seriousinjuryordeathcanoccur.
Preventtheharvesterheadfrommoving.
Alwaysensurethatthetiltframeisinthe
harvestingorprocessingpositionandthe
lockingpinisinstalled.
3.Insertlockingpininuprightposition(1).
4.Lowerharvesterheadtotheground.
5.Deactivatehydraulicinterlock.
6.TurnoffcarrierandturnWaratahswitchcontroltoOff
position.
CAUTION:Seriousinjuryordeathcan
occur.Preventinjuryfromyingorsharp
objects.Alwayswearapprovedglovesand
eyeprotectionwhenperformingsawchain
orsawbarmaintenance.
2
5
2
3
4
1
TX1086227—UN—03JAN11
RecommendedHarvesterHeadPositionsforTopSawChain
andTopSawBarMaintenance
1—LockingPininUpright
Position
2—FeedArm
3—UpperDelimbKnife
4—TopSawBar
5—LowerDelimbKnife
7.Pullthetopsawbar(4)outfromthetopsawbox.
