Safety:SafetySignsandLabels

ContinuedonnextpageT7M7G6M,000056B-19-26AUG20-1/2

HeadLabelsPositionsforLoaderProcessor

XJ1302494

LOCK Tilt frame with pin

supplied when servicing or carrying

out maintenance.

Personal injury or death may occur.

DANGER

WARNING

DANGER

KEEP AWAY

XJ1302494—19—26AUG20

1-5-3

053122

PN=28
