Safety:SafetySignsandLabels

T7M7G6M,000056B-19-26AUG20-2/2

XJ1302495

WARNING

LOCK Tilt frame with pin

supplied when servicing or carrying

out maintenance.

Personal injury or death may occur.

DANGER

KEEP AWAY

XJ1302495—19—26AUG20

1-5-4

053122

PN=29
