waratah HTH623C - Maintenance-Every 50 Hours or Weekly

Maintenance—Schedule
T7M7G6M,0000460-19-30AUG21-1/3
ContinuedonnextpageT7M7G6M,0000460-19-30AUG21-2/3
Maintenance—Every50HoursorWeekly
SPECIFICATIONS
FeedRollerNutT orque690N·m
510lb-ft
FeedRollerMountCapScrew
Torque
690N·m
510lb-ft
1.Completedailychecks.
2.Inspecttheframe,armsandknivesforcracksor
excessivewear.Replacecomponentsandsharpen
knivesasrequired.
3.Inspectandgreasethemeasuringwheelbearings.
4.Checkfeedarmpin(1)andfeedarmpincollar
retainingcapscrews(2),(ifinhardwoodapplications).
(SeePins.)
5.Checkconditionoffeedroller.(SeeFeedRoller.)
6.Checkfeedrollernuts(4).(SeeFeedRoller.)
7.Checkfeedrollermountcapscrews(3).T orquecap
screwstospecication.
8.Greasethelengthmeasuringrollerbearings.(See
FluidsandLubricants.)
4
3
1
4
2
TX1062643—UN—07AUG09
1—FeedArmPin
2—FeedArmPinCollar
RetainingCapScrew
3—FeedRollerMountCap
Screw(8used)
4—FeedRollerNut(5used)
SPECIFICATIONS
Fixedfeedmotormountcap
screwtorque
350N·m
258lb-ft
Measuringwheelmountcap
screwtorque
92N·m
68lb-ft
Measuringarmcapmountcap
screwtorque
81N·m
60lb-ft
9.Checkthecenterfeedmotormountcapscrew(5).
Torquethecapscrewstospecication.
10.Checkmeasuringwheelmountcapscrew(6)andarm
capmountcapscrew(7).T orquethecapscrewsto
specication.
5—Fixedfeedmotormount
capscrew
6—Measuringwheelmount
capscrew
7—Measuringarmcapmount
capscrew
7
6
5
XJ1298357—UN—10JUN20
3-2-3
053122
PN=65
