waratah HTH623C - Grease Point Location-Length Measuring Unit

Maintenance—FluidsandLubricants
T7M7G6M,000045A-19-19MAY22-1/1
GreasePointLocation—LengthMeasuring
Unit
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failingtofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
MeasuringUnitBody1
EndCap
1
MeasuringArmCylinder
1
Pin1
1—EndCap
2—MeasuringArmCylinder
BarrelEnd
3—MeasuringArmCylinder
RodEnd
4—MeasuringArmBody
2
1
TX1062610—UN—07AUG09
3
4
TX1062611—UN—07AUG09
3-1-9
053122
PN=58
