Maintenance—Every200—250Hoursor
Monthly
SPECIFICATIONS
TimberRite™H-16ControllerM8
Bolt
35N·m
24lb-ft
TimberRite™H-16Controller
BasePlateM10Bolt
63N·m
46lb-ft
ElectricalBracketMountingM12
BoltT orque
115N·m
85lb-ft
ControlValveMountingM16Bolt
Torque
285N·m
210lb-in.
CAUTION:Preventpossibleinjurywhileworking
inthearmcapturezonesorsawbaropening.
Keepawayfromthearmcapturezonesorthe
sawbaropeningoftheharvesterheadwhilethe
hydraulicsystemisactive.Failingtofollowthese
safetyprecautionsmayleadtoseriousinjury.
1.Completeweeklychecks.
2.CheckelectricalbracketmountingM12bolts(1).
Torquetheboltstospecication.
3.CheckTimberRite™H-16controllerbaseplateM10
bolts(5)andcontrollerM8bolts(6).
1—ElectricalBracketMounting
M12Bolt(3used)
5—TimberRite™H-16
ControllerBasePlateM10
Bolt(4used)
6—TimberRite™H-16
ControllerM8Bolt(4used)
1
6
5
XJ1241416—UN—07JUL17
TimberRite™H-16HeadModule
1
1
1
TX1058991—UN—04MAY09
TimberRite™HeadModule
TimberRiteisatrademarkofDeere&Company
4.CheckcontrolvalvemountingM16bolts(2).Torque
tospecication.
5.Checktheconditionofthetiltframepinsandbushes.
2—ControlValveMounting
M16Bolt(3used)
2
2
2
TX1056738—UN—05MAR09
ControlValveBracket
