waratah HTH623C - Grease Point Location-Top Saw Unit

Maintenance—FluidsandLubricants
T7M7G6M,0000456-19-19MAY22-1/1
GreasePointLocation—TopSawUnit
CAUTION:Whenservicingorcarryingout
maintenanceontheharvesterhead,always
ensurethetiltframeisintheharvesting
orprocessingpositionandthelocking
pinisinstalledandlowertheharvester
headtotheground.
CAUTION:Keepawayfromthearmcapture
zonesorthetopsawbaropeningofthe
harvesterheadwhilethehydraulicsystemis
active.Failingtofollowthesesafetyprecautions
mayleadtoseriousinjury.
1.Parkmachineonlevelground.
NOTE:Thetopsawcylindergreasepointscan
beaccessedthroughacutoutoneachside
oftheharvestinghead.
2.Stoptheengine.
3.AttachaDONOTOPERATEtaginanobviousplace
intheoperator'scab.
Location
Quantity
TopSawCylinder
2
2
1
TX1062563—UN—07AUG09
1—TopSawCylinderRodEnd2—TopSawCylinderBarrel
End
