waratah HTH623C

To Next Page

To Previous Page

Safety:SafetySignsandLabels

T7M7G6M,0000454-19-02JUN20-2/2

Injury to Human Body

(eyes and skin) may result

Laser radiation

Do Not stare into beam

Class 2 Laser product

XJ1212661—19—16MAR16

HeadLabelPositions

1-5-2

053122

PN=27
