Miscellaneous—Carrier
AM24480,00001A6-19-26SEP14-3/6
ContinuedonnextpageAM24480,00001A6-19-26SEP14-4/6
8.Disconnecttheheadmoduleconnectors(4—9).
4—ConnectorA
5—ConnectorB
6—ConnectorC
7—ConnectorD
8—ConnectorE
9—ConnectorF
8
6
4
9
7
5
TX1058993—UN—04MAY09
TimberRite™HeadModule
9.DisconnecttheCANinterfacesupplyconnector(10)
andpowersupplyconnector(11)ontheCrossFire™
module.
10—CANInterfaceSupply
Connector
11—PowerSupplyConnector
TX1058996A—UN—04MAY09
CrossFireModule
CrossFireisatrademarkofCrossCountrySystemsInc.
4-1-4
