Safety:MaintenancePrecautions
T7M7G6M,00006F1-19-30JUL21-2/2
Identicationofexcessivechainshotguard
wearanddamage:
•
Inspectforwearordamageofthechainshotguard,
capscrews,orattachinghardware.
•
Replacecapscrewsorhardwarewhenmissingornot
inplace.
•
Inspectforwearoneachendofthechainshotguard.
•
Inspectforpossiblecrackingonanyportionofthechain
shotguard.
•
Inspectforperforationsorholesanywhereonthesaw
chainshotguard.
•
Makesurethatthechainshotguardisnotwornthin
andstillmaintainstheoriginalshapeandprole.
•
Inspectforpossiblemetalpeelingortearingbackover
anyportionofthechainshotguard.
Replacethechainshotguardifanyofthesecondition
arepresent:
•
Theguarddoesnotmaintainitsoriginalshape.
•
Anyperforationispresent.
•
Anycracks,peeling,ortearingarepresent.
•
Thefront,side,orrearedgeiswornbymorethan5mm.
NOTE:Useonlyapprovedreplacementparts.
TX1305480A—UN—30OCT20
