waratah HTH623C - Page 4

Contents
Page
FellingonHillsides.............................................2-6-3
UsingLoadingProcessor..................................2-6-3
Operation:Miscellaneous
UnattendedHarvesterHead..............................2-7-1
DelimbingMulti-leaders.....................................2-7-1
Maintenance—FluidsandLubricants
RecommendedHydraulicSystemFluid............3-1-1
ChainOil............................................................3-1-1
Grease...............................................................3-1-2
GreasePointLocation—MainFrame................3-1-3
GreasePointLocation—TopSawUnit..............3-1-4
GreasePointLocation—TiltFrame...................3-1-5
GreasePointLocation—TiltFramefor
LoaderProcessor(Option)............................3-1-6
GreasePointLocation—TiltFramePin
GreasePoint.................................................3-1-7
GreasePointLocation—UpperDelimbKnives..3-1-8
GreasePointLocation—Length
MeasuringUnit..............................................3-1-9
GreasePointLocation—FeedArms................3-1-10
GreasePointLocation—LowerDelimbKnife..3-1-11
GreaseMeasuringWheelBearings.................3-1-12
GreasePointLocation—MainSawUnit
(3/4”SawOption)........................................3-1-13
Maintenance—Schedule
PeriodicMaintenanceRecord...........................3-2-1
Maintenance—Every8HoursorDaily..............3-2-2
Maintenance—Every50HoursorWeekly.........3-2-3
Maintenance—Every200—250Hours
orMonthly.....................................................3-2-5
Maintenance—Every1000Hours......................3-2-7
Maintenance—Every2000HoursorYearly......3-2-8
Maintenance—General
RecommendedHarvesterHead
PositionsforT opSawChainand
TopSawBarMaintenance............................3-3-1
RecommendedHarvesterHead
PositionsforMainSawChainand
MainSawBarMaintenance..........................3-3-2
Fault-Finding......................................................3-3-2
UniedInchBoltandCapScrew
TorqueValues...............................................3-3-3
MetricBoltandCapScrewTorqueValues........3-3-4
AdditionalMetricCapScrewTorqueValues......3-3-5
Maintenance—OperationCheckout
FaultFinding......................................................3-4-1
Miscellaneous—Carrier
PreventFires.....................................................4-1-1
InCaseofCarrierFire.......................................4-1-1
Weldingonthecarrierorharvesterhead..........4-1-2
WeldingonCarrierorHarvester
Head—TimberRite™.....................................4-1-3
Page
Usingboosterbatteries......................................4-1-7
UsingBoosterBatteries:TimberRite™.............4-1-8
Miscellaneous—Measurements
MetricandImperialUnitExpressions................4-2-1
Miscellaneous—SpecicationConversion
Length...............................................................4-3-1
Weight...............................................................4-3-1
Area...................................................................4-3-1
Volume..............................................................4-3-2
Pressure............................................................4-3-2
Flow...................................................................4-3-2
Liquid.................................................................4-3-2
Miscellaneous....................................................4-3-3
Miscellaneous:WoodMeasurement
WoodMeasurementEquivalents.......................4-4-1
ii
053122
PN=4
