5-62 Maintenance Procedures
7. Remove the metal gasket from the probe tip.
8. Dispose of the metal gasket in accordance with local environmental
regulations.
9. Remove the PEEK union/UNF coupling assembly and capillary from the
probe.
Warning: The metal gasket can be contaminated with
biohazardous and/or toxic materials. Dispose of it according
to local environmental regulations.
Metal gasket
PEEK union/UNF coupling assembly
Capillary
