Installation 3–1
3. INSTALLATION
3.1 SCHEDULE OF EQUIPMENT
The instrument has been carefully packed to prevent damage in transit. When removing the
instrument from the packing box, ensure that all parts and accessories are removed from the
packing material and have not been damaged. Retain the packing box and material.
The box will contain the following items as standard:
ITEM WAYNE KERR PART No QUANTITY
4310 (100kHz LCR Meter)
4320 (200kHz LCR Meter)
4350 (500kHz LCR Meter)
43100 (1MHz LCR Meter)
1J4310
1J4320
1J4350
1J43100
1
1
1
1
Power cord To suit destination country 1
4300 User Manual 9H4300 1
Kelvin Leads 1EVA40150 1
Options will be fitted to instrument as ordered and additional accessories ordered may be
packed in the same box or a separate box depending on size.
3.2 AC Line Connections
The unit is provided with a power cable capable of carrying the input current for both 115V and
230V operation. This cable should be connected via a suitable connector to the local AC power
supply. The colour code employed is as follows:
WIRE EUROPEAN N. AMERICAN
LIVE BROWN BLACK
NEUTRAL BLUE WHITE
GROUND GREEN/YELLOW GREEN
No adjustment is required for variation of supply voltage or frequency.
Before connecting the AC power, read the precautions listed under section 1.2—AC Power
Supply.
