4300 LCR Meter Specification 7–7
7.7.2 Rdc Accuracy
Resistance Range Accuracy
10Ω to 1MΩ ±0.2%
7.8 General
7.8.1 AC Input
Parameter Specification
Voltage 90 to 264V AC autoranging
Frequency 45 to 63Hz
Power 15W max
Input fuse* rating 1.6A T HRC
*The input fuse is in the fuse holder drawer integral to the IEC input connector.
7.8.2 Display
High contrast black and white LCD module 3.8” 1/4VGA (320 x 240 pixels) with CPL back
lighting.
7.8.3 Remote Control
RS232C
GPIB IEEE-488.2 (SCPI 1992.0)
7.8.4 Remote Trigger
Rear panel BNC with internal pull-up, operates on logic low or contact closure.
7.8.5 Mechanical
Parameter Specification
Height 104mm (4.1")
Width 322mm (12.7")
Depth 285mm (11.2")
Weight 3kg (6.6lbs)
