Wayne 4310 - 4300 Device-Specific Commands; Command Summary

REMOTE CONTROL (GPIB & RS-232) 5–13
5.3 4300 Device-Specific Commands
The sub-system commands are grouped in different modes similar to the local operation. The
recommended discipline to control the instrument under GPIB and RS-232 is to select the type
of test first, then change the measurement conditions. Trying to change measurement conditions
which are not in the present mode and type of test will be rejected and return an error flag.
5.3.1 Command Summary
Command Summary Page
:MEAS:TRIGger
Trigger an AC or Rdc measurement. 5–14
:MEAS:FREQuency <real>
Set frequency of AC measurement. 5–14
:MEAS:FREQuency?
Frequency query. 5–14
:MEAS:LEVel <real>
Set drive level for currently selected test. 5–14
:MEAS:LEVel?
Drive level query. 5–14
:MEAS:SPEED <disc>
Select measurement speed. 5–15
:MEAS:SPEED?
Speed query. 5–15
:MEAS:RANGE <disc>
Select auto-ranging or range-hold on range N. 5–15
:MEAS:RANGE?
Range query. 5–15
:MEAS:EQU-CCT <disc>
Select equivalent circuit. 5–16
:MEAS:EQU-CCT?
Equivalent circuit query. 5–16
:MEAS:FUNC1
Select first measurement function. 5–16
:MEAS:FUNC2
Select second measurement function 5-17
:MEAS:FUNC1?
First measurement function query 5-18
:MEAS:FUNC2?
Second measurement function query 5-19
:CAL:OC-TRIM <integer>
Perform open circuit trimming. 5–20
:CAL:SC-TRIM <integer>
Perform short circuit trimming. 5–20
:CAL:RES?
Returns the result of the calibration performed. 5–20
:TRIGger
Trigger a measurement in the current mode. 5–21
:DUMP-BMP
Returns the display as a windows compatible
bitmap.
5–21
