REMOTE CONTROL (GPIB & RS-232) 5–20
CALIBRATE MODE
:CAL:OC-TRIM <integer>
Perform open circuit trimming.
Parameters:
The required trim type.
4 All frequency
Example: :CAL:OC-TRIM 4
would perform an open circuit trim across the whole frequency range of the unit.
Response:
None.
:CAL:SC-TRIM <integer>
Perform short circuit trimming.
Parameters:
The required trim type.
4 All frequency
Example: :CAL:SC-TRIM 4
would perform a short circuit trim across the whole frequency range of the unit.
Response:
None.
:CAL:RES?
Returns the result of the most recent trim or calibration performed.
Parameters:
None.
Response:
The trim flag:
1 Calibration passed.
0 Calibration failed.
Example: 1
would indicate that the last trim or calibration was successful.
