REMOTE CONTROL (GPIB & RS-232) 5–19

MEASUREMENT MODE

:MEAS:FUNC2?

Second measurement function (Func 2) query.

Parameters:

None

Response:

Returns the measurement type according to this table:

0 Capacitance

1 Inductance

2 Reactance

3 Susceptance

4 Impedance

5 Admittance

6 Quality factor

7 Dissipation factor

8 Resistance

9 Conductance

10 Phase Angle

Example: 1

indicates that the second measurement is Inductance (L)
