4300 LCR Meter Specification 7–5
B2 version (isolated):
Parameter Specification
Output On State current: Up to 10mA at +24V
Output Off State current: <0.5mA
Output On State voltage: Input voltage -1.5V at 10mA
Input High current >3mA
Input Low current <1.25mA
Input High Voltage: >15.4V
Input Low Voltage: <8.0V
7.5.3 Save and Recall
20 different measurement set-ups can be saved and recalled
7.6 Measurement Connections
4 front panel BNC connectors permit 4-terminal connections with the screens at ground
potential.
Terminals withstand connection of charged capacitor up to following limits:
• a capacitor charged to between 50V and 500V with a stored energy of less than 0.25J,
either polarity.
7.7 Measurement Accuracy
Iso-accuracy charts define the specified accuracies, over the available frequency band and
impedance range. All curves assume that Slow measurement speed is used, that the instrument
has been trimmed at the frequency used for measurements, that factory calibration is valid and
that the component under test is pure.
For above and below the ranges indicated in the following charts, the accuracy degrades
linearly with increasing/decreasing DUT value.
