REMOTE CONTROL (GPIB & RS-232) 5–9
Summary Message
Event Summary Bit (ESB)
(Bit 5 of Status Byte Register)
Logical OR
P
o
w
e
r
O
n
U
s
e
r
R
e
q
u
e
s
t
C
o
m
m
a
n
d
E
r
r
o
r
Standard Event
Enable Register
*ESE <NR1> *ESE?
Standard Event
Enable Register
*ESR?
Execution Error Device Dependant Error
Query Error
Request Control Operation Complete
Figure 5-7 Event Status Byte Register
5.2.6.4 Event Status Enable Register
The event status enable register (ESE) is a mask determining the conditions in which the ESR
will set bit 5 of the SBR. It is bit-wise ANDed with the ESR and if the result is not zero then
ESB (bit 5) of the SBR is set (see Figure 5-7). Thus any event affecting the ESR can be made to
generate a Service Request in conjunction with the ERE and the SRE.
The event status enable is set by the *ESE command and read by the *ESE? command.
