Basic setting
4-17Profimat 23 E
Steel rollers
• Additional steel rollers (1) must be fitted on the
roller shaft so that the timber is covered
completely when processing very wide raw
timber. Note the direction of movement of the
steel rollers (1).
• Set the outfeed rollers (2) after the top spindle
to the middle of the workpiece in order to
prevent the timber running off to the side.
Wear protective gloves when fitting steel
rollers.
Pressure rollers (optional)
• Set pressure rollers (1) to the height of the feed
rollers (2).
(2)
(1)
(2)
(1)
