Setting up profiles
5-7Profimat 23 E
Set-up variation –
recall set values
(control system)
Positioning spindles via a control system.
Positioning the spindles in the machining
positions is described in detail in the Instruction
Manual for the control system.
Summary of control system
• Enter all tool and workpiece values in the
control system and save them as a program.
• Call up program.
Positioning
If the axes are not positioned automatically by a
positioning motor:
• Set the spindles to the working position as
shown by the numerical indicator and as
directed by the control system.
