Machine options
6-14 Profimat 23 E
270 mm
Working width 260 x 160 mm
(10.236" x 6.299")
Only tools with aluminium body may be used
when working with a width of more than
230 mm (8.661"). The tools must also include a
recess for the spindle nut.
(1) Tool
(2) Safety locking collar
(3) Spindle nut
For safety reasons, steel tools must not be used
at widths of more than 220 mm (8.661").
The following points must be noted when using
tools with aluminium body:
1. Aluminium tools must not be heated to more
than 120 °C when in service or when being
cleaned.
2. The solvents used to clean and remove resin
from aluminium tools must not corrode the
aluminium.
3. Tools which have been heated as a result of
cleaning in a washing machine or in any other
way must be allowed to cool before being
installed in the machine, otherwise the tool
mount can work loose or be reduced as the
tool shrinks on cooling.
(1)
(2)
(3)
(10.630")
