Tech. Dok. / L23 880 02 / 05.99.01 © MICHAEL WEINIG AG
Data, transport, start-up
8-7Profimat 23 E
Transport
Delivery
The markings on the packaging must be noted
without fail.
The machine may only be transported by a
qualified person familiar with such tasks.
Note the manual entitled ”Safety instructions“
when transporting the machine. The machine
has a tendency to tip backwards on account of
the heavy motors.
Transport the crate
• Ropes and the arms of a fork-lift truck should
be spread out as far as possible; the centre of
gravity is not necessarily in the center of the
crate.
Crated weight will be shown in the freight
documents.
Transport on a hook
Suitable hoisting gear of adequate strength is
required.
• Connect straps to appropriate hooks on left and
right.
• Connect straps to crane hook (1) or arms of a
fork lift truck (2).
• Carefully lift machine and lengthen or shorten
straps as required to balance machine.
• Ensure that machine hangs straight.
(1)
(2)
