PergoTex II/ PergoTex II LED
Instructions for assembly
We reserve the right to make technical changes
• If available, bolt support profile to the
bottom safety shield profile.
• To do this, push fixing slider 59 mm if
necessary.
• See Chapter 5.8
Adhesion of angle brackets 40x20x2 mm
to the safety shield
Note:
The angles 40x20x2 (1) mm seal the drill
holes in the safety shield profiles.
CAUTION:
All adhesive surfaces must be cleaned.
1. Adhere angle brackets 40x20x2 mm (1)
sideways with the the 40 mm side to
the safety shield (one left and one right)
using adhesive strips.
2. Adhere one angle bracket 40x20x2 mm
forwards with the 40 mm side to the
safety shield or the "safety shield
guttering" using adhesive strips.
Side angle bracket 40x20x2
Front angle bracket 40x20x2
