PergoTex II/ PergoTex II LED
Instructions for assembly
Version 9
05.10.2017
We reserve the right to make technical changes
Item number
118697-0000
Page 38/66
4.
Installation of the clip profile
1. Determine length of the clip profile (1).
2. Cut above and below the "pipe bend
cover" (2).
3. Insert the trimmed clip profiles (1)
above and below the "pipe bend cover"
(2) into the post (3).
Note:
The clip profiles are designed to fit loosely
rather than too tightly.
If the clip profile is seated too loosely, bend
it incrementally until the firm seating of the
clip profile is ensured.
