PEGASUS WING
1st Edition – March 2011 – Software Version: V1.0 R01
29
6.2. Selecting Sounds
On the right of the control panel are the selection and configuration facilities for sounds and
manuals (not for pedals).
6.2.1. Division of Levels for Sounds
The selection of sounds is divided according to each level as follows:
Upper 1 (right half 1) Upper 2 (right half 2 incl. WersiChord)
Lower 1 (left half 1) Lower 2 (left half 2)
The buttons for selecting sounds are divided into instrument groups.
The currently active main level changes when a button is
pressed (see also the label)
E.g.: Drawbars . the upper LED lights in the other main
level
E.g.: Presets . the lower LED lights
Tapping the button again switches back to the previous
main level.
So that all sounds can be allocated to all playing areas, there are also other levels on some
sound buttons (especially in the Upper2/Lower1/Lower 2).
These are selected in the display with the arrows / of these
buttons.
Tapping the lower arrow increases the level number, tapping
the upper arrow decreases it.
A list of all available sounds can be found at the end of this manual in Chapter 18.3 “List of
Factory Sounds” starting at page 94.
