PROCEDURE
Fig 10-13 SCR system - covers (example for 1 turbocharger)
V1
001
001
V2
Legend
001 Cover V2 SCR outlet valve
V1 SCR inlet valve
X72-B
AA00-9270-00AAA-520C-A
Operation Manual Connect the HP SCR system after isolation
Winterthur Gas & Diesel Ltd.
- 459 - Issue 003 2021-12
