GENERAL
L3301, L3901, L4701, WSM
G-91
Rear Axle Nut Wrench 71
Code No.
• 07916-52531
Application
• Use to remove and tighten a rear axle nut.
WSM000001GEG0040US0
Relief Valve Setting Pressure Adaptor G
Code No.
• 07916-52751
Application
• This allows easy measurement of relief valve setting pressure
from the hydraulic coupler. This is available with the relief valve
setting pressure tester.
WSM000001GEG0041US0
Safety Valve Tester
Code No.
• 07909-31361
Application
• Use to check the safety valve setting pressure.
Measuring range
• 0 to 50 MPa (0 to 500 kgf/cm
2
, 0 to 7200 psi)
9Y1210447GEG0092US0
Pinion Shaft Remover
Application
• Use for removing a pinion shaft.
• The special tool is not available, so make it. Refer to the
figure.
9Y1211012GEG0022US0
A 106 mm (4.17 in.)
B 350 mm (13.78 in.)
C 6 mm (0.24 in.)
D 90 mm (3.54 in.)
E 10 mm (0.39 in.)
F 40 mm (1.57 in.)
G 10 mm (0.39 in.)
H 35.6 mm (1.40 in.)
I 36 mm (1.42 in.)
J 41.6 mm (1.64 in.)
K Part code No. 3A201-4130 nut
L M27 × P1.5
M M10 × P1.25
