GENERAL
L3301, L3901, L4701, WSM
G-104
Front Wheels (4WD Model)
Front tread can not be adjusted.
IMPORTANT
• Do not turn front discs to obtain wider tread.
NOTE
• Wheels with beveled or tapered holes: Use the tapered side of lug nut.
9Y1211012GEG0043US0
Tire
8.3-16
Farm
27 x 8.50-15
Turf
27 x 10.50LL15
Turf
10-16.5
Industrial
305R343
Turf
Tread
1155 mm
(45.5 in.)
1200 mm
(47.2 in.)
1180 mm
(46.5 in.)
1195 mm
(47.0 in.)
1305 mm
(51.4 in.)
KiSC issued 09, 2016 A
